01Universal DIY gate frameComplete pre-engineered aluminum gate frame sized for the 4-foot-high by 6-foot-wide single-swing configuration.
02Wide lock side frameThe wide side profile is designed to coordinate with most U.S.-size lock hardware selected for the project.
03Top and bottom frameCoordinated top and bottom frame components complete the fully DIY frame design.
04Gate T-stopperThe gate-side stopper component is included as part of the Universal DIY frame system.
05Receiver L-stopper side postThe receiver-side L-stopper component helps finish the closing side of the gate opening.
065″ HD support hingeOne heavy-duty support hinge is listed with the kit. A hydraulic spring is sold separately when a true self-closing function is required.
078 ALU40 slatsEight 4-inch × 6-foot ALU40 aluminum slats are included for the 4×6 configuration in super-durable powder-coated black.
08Assembly-ready systemThe kit is designed around no-weld assembly, with the frame and components prepared for an intermediate DIY or contractor installation.
02Horizontal ALU40 designFour-inch aluminum slats create the clean horizontal rhythm associated with modern residential and light-commercial architecture.
03Adjustable privacyChoose the specified 3/8-inch or 1/2-inch gap to balance visual screening, airflow and the desired architectural expression.
04Rust-free aluminum6063-T6 aluminum avoids the iron-oxide rust cycle associated with ferrous gate materials.
05Exterior-ready finishAAMA 2604 architectural powder coating is used for long-term exterior color and finish performance.
06Factory-direct supportAluglobus Aluminum Systems supplies the gate system directly and can help contractors or serious DIY customers confirm the correct project package.
01Residential gatesA clean single-swing access gate for side yards, courtyards and residential pedestrian openings.
02Privacy fencing layoutsALU40 horizontal slats can coordinate the gate visually with modern aluminum fence systems.
03Courtyards and entrywaysThe 6-foot-wide opening gives a broad pedestrian entry while the 4-foot height keeps the gate visually open.
04Coastal propertiesAluminum and architectural powder coating are well suited to humid and salt-air environments with appropriate routine cleaning.
05Light commercial accessThe gate can serve controlled pedestrian openings where a clean, low-maintenance aluminum system is preferred.
06Contractor-led DIY installsThe no-weld system can simplify projects where a contractor handles site anchoring and alignment while using factory-prepared gate components.
02Frame assemblyConnect the universal gate frame with stainless-steel screws, keeping all corners square and secure.
03Slat installationCut and insert the ALU40 slats into the frame grooves, establish the selected spacing and secure each slat with the provided stainless-steel screws.
04Hinge installationAttach the heavy-duty hinge hardware to the side post and frame, then verify alignment for smooth swing operation.
05Post and gap cover installationAttach the side posts and gap-cover components to finish the wall-to-wall opening cleanly.
06Final touchesPress flat caps onto the posts, inspect the connections, confirm clearances and clean the aluminum surfaces.
01Verify 4′ high × 6′ wideMeasure the finished opening and confirm that this 4-foot-high by 6-foot-wide configuration matches the intended site.
02Confirm wall-to-wall mountingThe standard Universal DIY configuration is wall-to-wall only. Concrete footing requires an HD post upgrade requested in advance.
03Choose 3/8″ or 1/2″ gapSelect the slat spacing that gives the desired balance of privacy and openness before final assembly.
04Plan the lockLock hardware is not included. Confirm the selected latch or lock body and clearances for the wide lock-side frame.
05Plan self-closing hardwareThe included support hinge is self-closing capable, but a true self-closing setup requires the separate hydraulic spring specified for the project.
06Check swing clearanceConfirm the gate has unobstructed room to swing and that the mounting surfaces are aligned, rigid and suitable for the selected anchors.
