Aluminum systems
4' x 6' single-swing DIY pedestrian gate kit with interlocking ALU50-60 tongue-and-groove woodgrain profiles and no gaps between boards. The universal aluminum frame is built for wall-to-wall installs and a private, wood-look entry.
$939.18
ALU 50-60 T&G · Woodgrain · Universal DIY
The ALU 50-60 T&G Woodgrain 4×6 ft. Universal DIY Pedestrian Gate Kit is a 4 ft × 6 ft single-swing gate built around interlocking tongue-and-groove aluminum infill with no designed visibility gap. The Universal DIY format combines a pre-engineered aluminum frame, architectural woodgrain finish, corrosion resistance and straightforward field assembly for residential and light-commercial pedestrian access.
Gate size
4 ft × 6 ft
Configuration
Universal DIY · single swing
Privacy
T&G · no designed gap
Material
6063-T6 aluminum
ALU 60 T&G wood grain driveway gate project
Aluglobus Universal DIY Gate System
Built around architectural 6063-T6 aluminum, the system provides excellent corrosion resistance and low-maintenance exterior performance. The decorative woodgrain appearance adds warmth to the design, while the underlying gate structure remains aluminum rather than wood or conventional ferrous steel.
Technical construction first
This Universal DIY gate is designed as a complete framed assembly rather than loose fence material attached to hinges. The important details are the aluminum alloy, T&G privacy profile, universal frame geometry, hinge support, exterior finish and the mounting condition.
Architectural extruded aluminum provides a strong, lightweight and corrosion-resistant base for exterior gate construction.
4×6 single swing
Pedestrian-size Universal DIY gate format for a single swinging leaf.
ALU 50-60 T&G
Interlocking tongue-and-groove profiles create a continuous privacy field without a designed open slat gap.
Universal DIY
Pre-engineered frame system intended for tool-friendly assembly without field welding.
5″ HD support hinge
The Universal DIY gate family uses heavy-duty support hardware for the pedestrian swing.
AAMA 2604
Architectural coating specification with Cardinal Paint / TIGER finish systems used across the gate platform.
Non-combustible aluminum
The aluminum substrate does not ignite or sustain flame under normal fire exposure.
~615–655°C
Approximate melting range for the aluminum substrate: 615–655°C (1,139–1,211°F).
Defensible-space material consideration: The gate uses a non-combustible aluminum substrate. Project-specific compliance depends on the complete assembly, surrounding materials, required clearances, local code and the authority having jurisdiction.
Code-sensitive projects: aluminum is a non-combustible metal substrate. Requirements for the complete assembly, decorative finish, attachments, adjacent materials, clearances, and project-specific site conditions should be confirmed where applicable.
Product specifications
This model is designed for a full-privacy pedestrian entrance with a wood-look aluminum surface and a modular frame that can be assembled without welding.
Important mounting condition: Universal DIY gate systems are intended for wall-to-wall applications. For a freestanding opening, concrete-footing installation or a condition requiring structural posts, coordinate the appropriate heavy-duty post solution before ordering.
What’s included
The perimeter frame establishes the gate geometry and supports the T&G infill as a purpose-built pedestrian gate assembly.
The Universal DIY frame uses a wider side member to coordinate with common U.S.-size pedestrian lock hardware.
Interlocking aluminum profiles create the no-gap privacy field and the warm wood-inspired appearance.
Support hardware provides the pivot point for the single-swing pedestrian gate. Self-closing accessories can be coordinated separately when required.
The Universal DIY gate family uses a gate T-stopper and receiver L-stopper arrangement to finish the closing side of the opening.
Frame connectors and installation fasteners support the modular, weld-free assembly process.
Plan separately: Lock hardware, hydraulic self-closing spring, concrete footing, installation tools and site-specific anchors are not part of the basic gate package unless specifically added to the order.
ALU 60 T&G wood grain fence project
Why T&G changes the gate
Tongue-and-groove edges engage one another so the infill reads as a continuous architectural field.
Unlike spaced slat systems, the T&G layout is selected when privacy is the priority.
Interlocking infill helps establish consistent horizontal lines across the gate leaf.
The infill does not rely on structural wood boards that can swell, split or warp with repeated moisture cycles.
The gate is built from aluminum rather than combustible wood framing or wood infill.
The exterior keeps the warmer character of wood while the structural material remains aluminum.
Universal DIY system
The Universal DIY line is the modular option for projects where the gate mounts between suitable existing supports. It keeps assembly straightforward while still using a real perimeter frame, dedicated hinge hardware and a lock-side member sized for common pedestrian access hardware.
Use the Universal DIY configuration where the opening already has suitable rigid supports on both sides.
The pre-engineered frame and connectors are designed for mechanical assembly with standard installation tools.
The wide lock side gives installers room to coordinate common U.S.-size gate lock hardware.
Freestanding posts, concrete-footing conditions or higher structural demands should be coordinated with the appropriate HD post or Contractor Line configuration.
Universal DIY application: this gate system is intended for appropriate wall-to-wall installations. Verify the finished opening dimensions, structural mounting surfaces, hinge orientation, swing clearance, lock hardware, and site conditions before assembly and installation.
Woodgrain aluminum
The wood-look surface arrives finished and does not require a recurring stain schedule.
There is no structural wood substrate that must be periodically sealed against moisture.
Aluminum avoids the red-rust mechanism associated with ferrous gate frames and infill.
AAMA 2604 finish materials are specified for exterior architectural exposure and long-term color performance.
Corrosion-resistant aluminum is well suited to humid and salt-air environments when maintained appropriately.
Wood-look finish availability can vary. Confirm the current IPE, Teak, White Oak or other available production finish before ordering.
Wood look, aluminum construction: this system is designed to deliver the architectural warmth of a wood-style gate while maintaining an aluminum gate structure underneath. This avoids many of the maintenance concerns associated with natural wood while preserving a premium woodgrain appearance.
Applications
Create a private transition between the street-facing side of a property and the rear yard.
Use the woodgrain T&G field where a warmer architectural entry is desired without switching to structural wood.
Coordinate the aluminum wood look with landscape materials, patios and contemporary exterior finishes.
Pair the no-gap gate with compatible T&G fence layouts to maintain a continuous privacy concept.
Aluminum’s corrosion resistance makes it a practical option for demanding exterior climates.
Use the 4×6 pedestrian format for controlled walk-through points where low recurring maintenance matters.
Installation sequence
Measure the final wall-to-wall condition and confirm that both mounting surfaces are rigid, aligned and suitable for the selected anchors.
Choose the hinge side, swing direction and lock or latch hardware before final frame positioning.
Connect the Universal DIY frame components, square the corners and verify the finished gate dimensions before infill installation.
Insert the woodgrain tongue-and-groove profiles in sequence so the interlocking field remains aligned and fully seated.
Install the hinge support and closing-side stop components, then hang the gate on the prepared opening.
Check reveal, swing, closure and lock alignment, then tighten final hardware and clean the finished aluminum surfaces.
Confirm the actual width and height at the completed mounting surfaces, not an early rough opening.
Verify that the Universal DIY mounting format matches the site. If structural posts are required, coordinate that before ordering.
Choose the hinge side and confirm the gate can open without interfering with stairs, walls, equipment or walk paths.
Select the access hardware early so frame clearances and the receiver side can be coordinated correctly.
Confirm the exact available woodgrain tone and match it with adjacent fence, cladding or architectural materials.
If the gate must self-close, coordinate the correct spring or hydraulic hardware and any project-specific safety requirements before installation.
Product videos
Watch the product-specific Universal DIY gate video, then open the Aluglobus gate-construction video for a closer look at how the system is built.
Factory-direct Universal DIY gate system
Confirm the 4 ft × 6 ft opening, wall-to-wall mounting condition, swing direction, lock selection and woodgrain finish before ordering. Aluglobus Aluminum Systems can help coordinate the correct gate package and optional support hardware for the site.
Frequently asked questions
Review the no-gap T&G system, Universal DIY mounting condition, woodgrain finish, included hardware and planning requirements before ordering.
The ALU 50-60 tongue-and-groove profiles interlock to create a continuous privacy surface with no designed open gap between the horizontal infill profiles.
Yes. The Universal DIY system is designed for mechanical assembly without field welding. Accurate measurements, rigid mounting surfaces, correct anchors and careful alignment are still required.
The Universal DIY configuration is intended for wall-to-wall applications. If the opening requires posts set in concrete or a freestanding structural condition, coordinate an appropriate heavy-duty post or Contractor Line solution before ordering.
The basic Universal DIY gate package is centered on the gate frame, T&G infill, hinge support, stops and assembly hardware. Posts, lock hardware, concrete footing, self-closing hydraulic hardware and installation tools should be selected separately when required.
No routine wood staining or sealing is required because the gate is aluminum with a finished woodgrain surface rather than a structural wood gate.
Yes. The gate uses a non-combustible aluminum substrate. Final project compliance depends on the complete assembly, surrounding materials, clearances and applicable local requirements.
Self-closing capability can be coordinated with the hinge system, but true self-closing performance typically requires a suitable spring or hydraulic closer selected for the gate and project requirements.
Typical applications include side-yard entrances, courtyards, backyard access, privacy-fence transitions and other residential or light-commercial pedestrian openings with suitable wall-to-wall supports.
Aluglobus Aluminum Systems
Factory-direct aluminum gate systems for homeowners, contractors, builders, designers and serious DIY projects. Nationwide shipping and product support are available.
Aluglobus Aluminum Systems · Aluminum gates · Fence systems · Patio covers · Wall cladding · Nationwide supply
Real projects
Completed installations by Aluglobus Aluminum Systems using this system. Sizes, layouts and accessories vary by project.
Watch
Installation, product and factory videos from Aluglobus Aluminum Systems.
Specifications
Check sizes, material and configuration against your project before ordering.
Complete the system
Universal DIY pedestrian gate kits and the matching DIY gate frame kits. The frames are designed to go together without welding and take ALU 20, ALU 40 or ALU 50/60 T&G infill depending on the kit.
Measure the opening and check it is a wall-to-wall installation, or ask about the HD post option.
Choose the size (4×6, 6×6 or 6×8 ft frame) and the infill: ALU 20, ALU 40 or T&G.
Choose black or wood grain where offered.
Add a latch, cane bolt or stopper if your layout needs one.
Send photos of the opening if you are unsure about hinge side or swing direction.
