Aluminum systems
A 4x4 in. HD square post, 8 ft long with a .125 wall, in black 6063-T6 aluminum with AAMA 2604 powder coating, listed for pedestrian and sliding gates set in concrete.
$179.74
Gates put more load on their posts than any other part of a fence. The 4×4 in. x 8ft. HD Square Post (.125 Thk) from Aluglobus Aluminum Systems is a 4×4 aluminum gate post 8 ft long, with a .125 wall thickness, the heaviest wall among the square posts in our price list. It is listed for pedestrian gates and sliding gates.
In the pedestrian gate post options, this post appears as the concrete footing option: Option 5 Concrete Footing – 4×4 in. x 8ft. HD Square Post (.125 Thk). The heavy-duty sliding gate kits also list a 4 in. square post for concrete footing as one of their two post options, alongside a 3 in. post. That makes the 4×4 in. post the choice when you want a free-standing gate post set in concrete rather than a wall-mounted one. Explore compatible gates in our aluminum gates range, including the DIY sliding gate 19 ft x 6 ft.
The same 4×4 in. HD post is listed in three lengths:
Work out how much post you need above grade for your gate height and hardware, then add the depth your footing requires. If 8 ft covers both, it is the easiest length to handle and set; if not, step up to 11 ft or 12 ft. Footing size and depth should follow the included instructions and your local code, and our team can confirm the right length for your gate.
Close the top of the post with the 4" flat press cap, which is listed for 4 in. square posts. Hinges, latches, guide rollers and gate catchers are sold separately; check the hardware list for your gate and confirm fit on the 4×4 in. profile with our team before drilling.
Material & finish
4×4 in. x 8ft. HD Square Post (.125 Thk) – Black is made from aluminum 6063-t6, finished with AAMA 2604 Super-Durable Powder Coating in black.
6063-T6 is an architectural aluminum alloy made for extruded profiles. It gives clean, consistent shapes and takes a powder coating evenly, which is why it is widely used for fences, gates and other exterior building products.
AAMA 2604 is the American Architectural Manufacturers Association specification for high-performance organic coatings, powder coatings included, on aluminum extrusions. It sets test requirements for outdoor color and gloss retention, chalking and corrosion resistance.
Material
Aluminum 6063-T6
Finish
AAMA 2604 Super-Durable Powder Coating
Color
Black
Wall thickness
.125
Ordering
Watch
Installation, product and factory videos from Aluglobus Aluminum Systems.
Specifications
Check sizes, material and configuration against your project before ordering.
Complete the system
Square aluminum posts (2×2, 3×3, 3.15 and 4×4 in.) with C-channel kits, C-channel and channel-cover spacers, press caps and base plates, as used on the Aluglobus fence kits and gates.
Choose the post size and wall thickness for the job (light duty or HD).
Match the cap to the post size (2, 3, 3.15 or 4 in.).
Add C-channel kits for each post face that holds slats, and the spacers that set the gap.
Decide between posts set in concrete and base plates (anchors sold separately).
Confirm color and lengths before ordering.
FAQ
Send your measurements and photos. Our team will help you choose the right system and parts.
It is listed for pedestrian gates and sliding gates, and appears as the concrete footing post option for gates.
No. The 4" flat press cap, listed for 4 in. square posts, is sold separately.
The 4x4 in. HD square post (.125 Thk) is listed in 8 ft., 11 ft. and 12 ft. lengths.
Yes. The heavy-duty sliding gate kits list a 4 in. square post for concrete footing as a post option.
Footing size and depth depend on your site and local code. Follow the included instructions and confirm with our team.
