01 Universal DIY gate frame The aluminum frame forms the structural perimeter of each gate leaf and is assembled square with stainless-steel screws.
02 ALU40 woodgrain slats Horizontal aluminum infill supplies the wood-look surface while retaining the corrosion resistance and dimensional stability of aluminum.
03 Stainless-steel fasteners The current instructions reference stainless-steel screws for both frame assembly and securing the ALU40 slats.
04 Heavy-duty hinge points Hinges are aligned between the gate frame and side supports so both leaves can swing cleanly without binding.
05 Side and finishing pieces Side components and flat caps finish the system after the frame, slats and hinge alignment have been completed.
06 Site-specific hardware Confirm posts or mounting surfaces, center-stop strategy, latch or lock, clearances and any automation hardware for the actual opening before installation.
01 Warm architectural finish Woodgrain brings a natural visual texture to the clean horizontal proportions of the ALU40 gate system.
02 Lower finish maintenance The gate does not depend on a wood substrate that needs routine staining, sealing or repainting to preserve its appearance.
03 Corrosion resistance Aluminum avoids the iron-oxide rust mechanism associated with ferrous gate materials and is well suited to exterior exposure.
04 Non-combustible material The product listing identifies the structural material as non-combustible aluminum for projects where material selection matters.
05 Field-set privacy rhythm The current installation sequence allows ALU40 slat spacing to be coordinated during assembly instead of forcing the fixed gap used on some other SKUs.
06 Factory-direct support Custom sizes and color options can be coordinated for openings that require more than the standard 12′ × 6′ package.
01Residential drivewaysCreate a coordinated double-swing entrance with the visual warmth of woodgrain and an aluminum structural system.
02Estate entrancesThe 12′ × 6′ format gives larger residential entries a stronger architectural presence than a small pedestrian gate.
03Backyard accessUse a wider opening where equipment, trailers or larger access paths require more clearance than a single gate leaf.
04Coastal projectsCorrosion-resistant aluminum is well suited to humid and salt-air environments when the system is properly maintained.
05Light commercial accessA modern double-swing solution for projects that want a clean horizontal gate appearance without a traditional wood frame.
06Fence-and-gate coordinationCoordinate ALU40 horizontal infill with surrounding aluminum fence layouts for a more continuous exterior design.
01PreparationOrganize the frame, ALU40 slats, fasteners, hinges and finishing pieces in a clean work area. Confirm the opening and gate-leaf plan before cutting.
02Frame assemblyConnect the Universal DIY frame with stainless-steel screws and keep the corners square before the infill is installed.
03Slat installationCut and insert the ALU40 slats into the frame grooves, establish the intended spacing, then secure each slat with the provided stainless-steel screws.
04Hinge installationAttach and align the heavy-duty hinge points between the side supports and gate frames so both leaves can operate smoothly.
05Side and gap finishingInstall the side components and finishing pieces after the final mounting condition, center relationship and clearances have been confirmed.
06Final adjustmentInstall caps, tighten connections, verify swing and closure on both leaves, then clean the finished aluminum surfaces.
01Verify the finished openingMeasure the actual clear opening and confirm how the 12′ × 6′ nominal gate package relates to posts, walls and required operating gaps.
02Plan both gate leavesConfirm center meeting conditions, leaf widths, hinge sides and the swing path before frame assembly begins.
03Set the privacy rhythmChoose the desired ALU40 spacing before cutting and fastening the horizontal slats so both leaves match visually.
04Check structural supportsMounting posts or walls must be rigid, aligned and appropriate for the hinge loads and selected anchors.
05Choose access hardwarePlan the latch, lock, drop rods, center stop or other closing hardware required by the actual double-swing configuration.
06Plan automation earlyIf the project will use operators or access control, coordinate that hardware before finalizing frame, hinge and stop conditions. Do not assume automation hardware is included with the gate kit.
